TOKYO, Japan, July 10, 2025 – Renesas Electronics has introduced the RA2T1 microcontroller (MCU) group, featuring the Arm Cortex-M23 processor and optimized for motor control systems. RA2T1 devices are designed for single-motor applications such as fans, power tools, vacuum cleaners, refrigerators, printers and hair dryers.
Feature Set Optimized for Motor Control
The RA2T1 devices add features to support motor control in single-motor systems. They include a three-channel sample-and-hold function that measures all three phase currents of Brushless DC (BLDC) motors simultaneously, improving control accuracy over sequential measurements. The RA2T1 MCUs also provide a complementary pulse width modulation feature in the timer, which enables automatic dead-time insertion and supports asymmetric PWM generation. These functions are designed for inverter drive applications and help simplify control algorithm implementation.
The RA2T1 devices offer safety features that are critical in motor control applications. They provide a Port Output Enable function and a high-speed comparator that work together to shut off the PWM output when an overcurrent is detected. The shutdown state can be selected according to the inverter specifications.
Renesas Leadership in Embedded Processing for Motor Control
Renesas has shipped motor-control specific MCUs for over 20 years. The company ships over 230 million motor control embedded processors per year to worldwide customers. In addition to multiple RA MCU groups, Renesas offers motor-control devices in its 32-bit RX family, its 16-bit RL78 MCUs and its 64-bit RZ MPUs.
“Customers have trusted Renesas motor control solutions for many years across thousands of systems,” said Daryl Khoo, vice president of embedded processing marketing division at Renesas. “The RA2T1 MCUs enhance our leadership in this area with market-leading technology, low-power operation, and legendary Renesas quality and safety standards for single-motor systems.”
Key Features of the RA2T1 Group MCUs
- Core: 64 MHz Arm Cortex-M23
- Memory: 64KB Flash, 8KB SRAM, 2KB Data Flash
- Analog Peripherals: 12-bit ADC with 3-channel sample and hold, temperature sensor, internal reference voltage, 2-channel high-speed comparators
- System: High-, mid- and low-speed on-chip oscillators; clock output; power-on reset; voltage detection; data transfer, event link and interrupt controllers; low-power modes
- Safety: PWM forced shutdown, SRAM parity error check, ADC self-diagnosis, clock frequency accuracy measurement, illegal memory access detection
Operating Temperature Range: Ta = -40°C to 125°C
Operating Voltage: 1.6V to 5.5V
Packages: 48LQFP, 32-LQFP, 48-QFN, 32-QFN, 24-QFN (4mm x 4mm)
Renesas’ Flexible Software Package (FSP) supports the RA2T1 Group MCUs. FSP provides infrastructure software including RTOS options, BSP, drivers, middleware, connectivity, networking, and security stacks, along with reference software for building AI, motor control, and cloud applications. Developers can integrate their code and preferred RTOS with FSP, allowing flexibility in application development. FSP also simplifies migrating motor control designs to other devices in the RA Series.
Winning Combinations
Renesas has combined the RA2T1 Group MCUs with compatible devices from its portfolio to offer an array of Winning Combinations, including Portable Power Tools, Smart BLDC Ceiling Fan, Cordless Vacuum Cleaner, Cordless Leaf Blower. Winning Combinations are verified system architectures built from compatible Renesas products, designed to reduce design complexity and development risk. Renesas offers 400 Winning Combinations to help customers streamline product development and accelerate time to market.
They can be found at renesas.com/win.
Availability
The RA2T1 Group MCUs are available with FSP software. They are supported by the Renesas flexible motor control development kit, which allows evaluation of motor control with magnet synchronous (brushless DC motors). The MCUs are also compatible with the Renesas Motor Workbench tool. The development kit uses motor control MCUs from the RA and RX families and supports migration of IP between devices.
Information on all these offerings is available at renesas.com/RA2T1.
Renesas MCU Leadership
Renesas ships more than 3.5 billion microcontroller units each year. About half support the automotive industry. The rest are used in industrial, Internet of Things, data center, and communications infrastructure applications. Renesas has the portfolio of 8-, 16- and 32-bit devices, delivering with quality and performance. Renesas has substantial experience designing smart and secure MCUs, backed by a dual-source production model and a network of more than 250 ecosystem partners.
For more information about Renesas MCUs, visit renesas.com/MCUs.
