GENEVA, Switzerland, June 23, 2026 – STMicroelectronics’ VL53L9 adds direct Time-of-Flight 3D LiDAR depth sensing to low-compute edge AI systems built around small microcontrollers. The module provides AI-ready output data for robotics, industrial automation, smart buildings, AR/VR, consumer electronics and healthcare applications, targeting designs where system size, processing overhead and integration complexity are limiting factors.
“VL53L9 demonstrates how far Time-of-Flight sensing has evolved, combining high-resolution depth data, up to 100 frames per second, and a fully integrated architecture in a single compact module. By simplifying integration and reducing system complexity, we enable customers to accelerate the development of applications such as robotics, smart infrastructure, and healthcare monitoring,” said Alexandre Balmefrezol, executive vice president and general manager of the Imaging sub-group at STMicroelectronics. “This launch reflects our strategy to move beyond standalone sensors and deliver integrated sensing systems that support real-world edge AI.”
“3D sensing demand accelerates across robotics, industrial automation, XR, and intelligent consumer devices. Time-of-Flight technology is expanding beyond smartphones into applications requiring compact, affordable, and precise depth perception, from navigation and people monitoring to gesture recognition and safety. Higher resolution multizone dToF modules are now emerging as key enablers for this next wave of 3D sensing adoption (1),” said Anas Chalak, market & technology analyst at Yole Group.
Target Applications
ST positions the FlightSense VL53L9 for application areas:
- Robotics: small-object detection, simultaneous localization and mapping, and obstacle avoidance for autonomous navigation.
- Industrial automation: volume measurement in tanks and bins to support inventory management and operations.
- Smart buildings and homes: human presence detection and people counting while preserving user privacy.
- AR/VR and consumer electronics: gesture recognition, body tracking and finger skeleton applications.
- Healthcare: fall detection and monitoring systems for eldercare and patient safety.
Technical Information
Depth Sensing Performance
The VL53L9 provides 2,268 resolution zones, arranged as 54 × 42, with a 54° × 42° field of view for 3D depth mapping and detection of small objects, contours and edges.
The module uses BSI SPAD sensor technology and meta-surface optical elements. It supports ranging from less than 5 cm up to 9 meters, with up to 1% accuracy and a frame rate of 100 frames/second.
Illumination and Processing Architecture
The module uses dual-scan flood illumination instead of dot scanning. This approach:
- reduces motion artifacts;
- eliminates dead zones;
- improves small-object detection;
- captures 2D infrared and 3D depth images.
The architecture is designed to simplify post-processing and support edge AI workloads on small MCUs with low compute requirements.
The VL53L9 integrates on-chip dToF processing and a dedicated power management IC. It is calibration-free, which simplifies integration and reduces system cost and complexity.
Module Design and Interfaces
The module measures 12.8 mm × 6.1 mm × 4.6 mm and is supplied as a reflowable, single-component device compatible with a range of cover glass materials. It supports dual power supply operation at 1.2 V and 3.3 V and outputs data through MIPI or I3C interfaces for compatibility with different CPU architectures. The module is certified as Class 1 laser safe.
Availability
ST FlightSense VL53L9 will be mass produced from early July 2026
(1) 2025 – 2030 period; Source: 3D Imaging & Sensing 2025 report, Yole Group
Source: STMicroelectronics
